RIGOL Technologies announced the official release of its new DNA5000/6000 Series Vector Network Analyzers (VNA). By combining dependable RF performance with unprecedented ease of use, the new series is designed to bring professional-grade network analysis to every engineer’s workbench.

Reliable Performance — Ready for Core RF Testing

Introducing accessible test tools should never mean compromising performance. The DNA5000/6000 Series delivers solid core RF specifications that make it well-suited for most R&D and diagnostic tasks right on the bench.

• A wide frequency range from 5 kHz to 26.5 GHz, with both 2-port and 4-port options, accurately covers testing needs from basic passive components (such as filters, antennas, and cables) to dielectric material characterization and high-speed interconnects.
• With a dynamic range greater than 120 dB and very low trace noise, the series ensures accurate characterization of high-rejection devices and stable measurement results.
• Fixture removal and de-embedding features let users strip away the effects of test fixtures, adapters, and cables, yielding precise S-parameter measurements of the device under test (DUT) itself.
• Built-in application tools such as limit testing (Pass/Fail), SWR measurement, Smith chart display, and Time Domain Reflectometry (TDR) support both development verification and production quality control with high efficiency.

Intuitive and Accessible — Designed for Every Engineer

To bring VNA capability to every bench, lowering the usage barrier was paramount. The DNA5000/6000 Series introduces revolutionary interactive design that makes advanced vector network analysis easier than ever.

• The integrated calibration wizard guides users step by step through setup, allowing both beginners and experienced engineers to calibrate quickly and accurately for reliable measurement results.
• A modern, high-resolution touchscreen supports smooth touch, drag, and gesture interactions to enhance workflow efficiency.
• Support for standard SCPI commands, compatible with mainstream vendor command sets, enables seamless integration into existing test systems without rewriting automation scripts, preserving familiar workflows.
• A comprehensive set of connectivity options — including HDMI, LAN, USB, and GPIB (DNA6000 only) — facilitates external displays, remote control, and easy integration into automated test environments.

Complete Ecosystem — One-Stop Reliable Testing

RIGOL provides not just an instrument, but a complete RF test solution ecosystem, enabling engineers to fully equip their setups for reliable testing.

• High-precision mechanical calibration kits cover different frequency bands and connector types with durable, traceable standards that ensure high repeatability.
• Electronic calibration (ECal) modules deliver one-connection, fully automated calibration, significantly reducing setup time and minimizing human error — ideal for environments focused on efficiency and consistency.
• Lab-grade RF cables with ultra-low insertion loss and excellent phase stability ensure signal integrity even in demanding test conditions.

Dual Options — Tailored for Different Applications

Understanding that workspaces and testing needs vary, RIGOL offers two different form factors for the DNA Series.

• The compact, portable DNA5000 Series is perfect for limited bench space or shared use across multiple labs, making deployment and mobility simple.
• The classic benchtop DNA6000 Series is recommended for fixed R&D platforms or high-stability automated production lines, providing robust performance for long-duration, high-intensity testing and easier integration into standard test racks.

With professional design, intuitive interaction, powerful performance, and a complete ecosystem, the RIGOL DNA5000/6000 Series vector network analyzers aim to lower the barrier to advanced network analysis. More than just instruments, they represent RIGOL’s commitment to making advanced RF testing accessible and enabling engineers everywhere.
